Model Name | BTHH-LS250-W |
Dimension | 240mmL*121mmD*119mmH |
Weight | 2 Kg |
Power Consumption | AC 100~240V ± 10% , 50/60 Hz |
Supply Voltage | By Fuse 80 V/ 1.5A [Ø5*20mm] |
Input Power Protection | 0℃ ~ 40℃ , 10%~80% |
Operating Circumstance | -20℃ ~ 60℃ , 5%~90% |
Illumination Control Method | Manual:By KEY Remote:RS-232C |
LED Window Displays | YES |
ON/OFF Control | by KEY / RS-232C |
Brightness | Over 480,000Lux (White Color) |
Illumination Dimming Range | 0~255 |
Ferrule/Fit Filber Diameter | 15mm(Inner)/13mm |
Error Diameter | FAN ,Temperature |
Cooling Method | FAN Forced Air Cooling |
Luminous Color | White |
Color Temperature | 6500°K±500°K / 3000K°K±500°K |
Lamp Lifetime | 20,000Hr |
LED燈箱
LED 250W光源燈箱
LED 250W光源燈箱
•長壽命 20,000Hrs
•獨自散熱技術
•無需使用耐熱光纖
•低總消耗功率(80W)
•RS-232C通訊(選項)
•獨自散熱技術
•無需使用耐熱光纖
•低總消耗功率(80W)
•RS-232C通訊(選項)
